Construction
Only polyolefin bicomponent fibers (ES fibers) are used, thermally bonded, with fiber-to-fiber bonding forming a stable porous structure.
Quality:
- CP filter materials comply with FDA CFR 21.
- Compliant with RoHS regulations.
- Compliant with REACH regulations.
- Manufactured in ISO 9001 certified facilities.
- Manufactured in ISO 14001 certified facilities.
Filtration Grade
| Nominal Rating | 1, 3, 5, 10, 25, 50, 75, 100, 125, 150, 200 micron |
Specifications
| Component | Material |
| Filter media | Polyethylene và Polypropylene |
| End components | Polypropylene |
| O-ring | NBR, EPDM, Silicone, FKM (Fluorine Rubber) E-FKM (Encapsulated Fluorine Rubber) |
Size
| Inner Diameter | 0.98” |
| Outer Diameter | 2.76” |
| Length | 10”, 20”, 30”, 40” |
Product Applications:
| General industry | Washing water, primary filtration for ultrapure water, etc. |
| Chemical industry | Paints, printing inks, plastics, adhesives, catalysts, solvents, surfactants, etc. |
| Food industry | Tea, fruit juices, wine, spirits, soy sauce, soups, vinegar, syrups, etc. |
| Electronics industry | Purified water, optical films, PCB, FPC, photomasks, lead frames, TAB, electrolytic copper foils, ceramic capacitors, resistors, etc. |
